characteristic:

1. A full set of Russian electronic tubes with sweet and delicate sound, wide sound field and strong dynamics.

2. The fully original top Japanese Guhe enamelled wire is fully manually wound (the enamelled wire is directly purchased and shipped from Japan, with high purity) to avoid the sound defects of machine winding.

3. The transformer adopts imported h14 0.35mm silicon steel sheet (new Japanese silicon steel sheet), which is wound in layers and sections, and the process is first-class

4. The fuselage adopts all aluminum fuselage and advanced CNC processing, with fashionable appearance and artistic sense.

5. Imported filter capacitor, Dale resistor and Wima coupling capacitor are used for internal parts

appearance

Length: 370mm width: 225mm height: 195mm

Weight: 15kg

Chassis material

The fuselage adopts all aluminum fuselage and advanced CNC processing

Output power: 7W * 2

Input sensitivity: 1V

Signal to noise ratio: 80dB

Frequency response range: 10hz-22khz

Output terminal: 4 Ω / 8 Ω

Total harmonic distortion: 1.5%
